5.5" x 5.5" to 8.5" x 14" (140 x 140mm to 216 x 356mm)
Maximum Original Size
Up to 8.5" x 14" (216 x 356mm)
Supported Paper Sizes
Standard Tray: 5.5" x 8.5" to 8.5" x 11" Optional Tray: 8.5" x 11" to 8.5" x 14" Bypass Tray: 5.5" x 8.5" to 8.5" x 14" Duplex Unit: 8.5" x 11" to 8.5" x 14"
Supported Paper Weights
Standard/Optional Trays: 16 – 24 lb. Bond (60- 90gsm2) Bypass Tray: 16 – 42 lb. Bond (60- 157gsm2) Duplex Unit: 20 – 24 lb. Bond (60- 90gsm2)
Standard: 250 sheets + 100-Sheet Bypass Tray Optional: 500 sheets x 1 or 2 Trays
Maximum Paper Capacity
1,350 sheets
Standard Output Capacity
250 sheets (internal tray)
Maximum Monthly Volume
5000
Power Source
120V, 60Hz, 8A
Typical Electricity Consumption (TEC)
0.696 kWh/week TEC value is measured based on the ENERGY STAR Ver.3.0 test method.
Power Consumption
Operating: Less than 1.1 kW (max) Sleep Mode: 2.8 W
Dimensions W x D x H
19.0" x 17.7" x 18.1" (476 mm x 450 mm x 451 mm) – mainframe, includes ARDF
Weight
57.3 lbs./ 26 kg.
Standard Features
Document Server*, Image Rotation, Auto Off Timer, Combine Copy, Electronic Sort, Energy Saver Timer, Photo Mode, SeriesCopy, Job Programs (25), User Codes(8 digits, 1,000 Personal Codes)
Footnotes
*HDD required
PRINTER SPECIFICATION
Processor Speed
RM7035C – 533 MHz
Hard Disk Drive
Optional: 128 GB HDD
Interfaces
Standard Interfaces: Ethernet (RJ-45 network port : 10Base-T/100Base-TX), USB2.0 Type A and B Optional Interfaces: IEEE1284, Wireless LAN (IEEE802.11a/b/g),Giga Ethernet (1000BASE-T), Bluetooth
Network Protocol
TCP/IP (IPv4, IPv6), IPX/SPX (available with Netware option)
Supported Operating Systems
Windows XP/Server 2003/Vista/Server 2008/7; Novell Netware 6.5; UNIX Filters for Sun Solaris 2.6/7/8/9/10; HP-UX 10.x/11.x/11iv2/11iv3; Red Hat Linux Enterprise V4, V5, V6; SCO OpenServer 5.0.6/5.0.7/6.0; IBM AIX Version 5.3, 6.1, 7.1; SAP R/3, 3.x or later, mySAP, ERP2004 or later; Mac OSX 10.2 or later, Citrix Metaframe XP/ Presentation Server 4, 5/XenApp 5.0, 6.0
Fonts for PCL 5e/6: 45 Roman fonts Fonts for PS3: 136 Roman fonts
Print Resolution
600 x 600 dpi
Printer Features
Media Direct Print (Print from USB/SD), Mobile Driver, Bonjour Support, Classification Code, Mail to Print1, PDF Direct Print, Sample/Hold/Stored/Locked Print, Store and Print, Windows Active Directory Support, DDNS Support, WSPrinter, PCL resident font adoption, Tray-Parameter Change from WebImageMonitor, XPS Support
Security Features
Quota Setting/Account Limit; SMTP over SSL; Hard Disk Data Overwrite Security¹; Authentication (Windows/LDAP/Kerberos/Basic/User Code/802.1.x Wired); Encryption (Address Book/Authentication Password/SSL Communication/S/MIME/IPsec/Locked Print Password/HDD1); Network Protocol (Port) On/Off; IP Filtering; Copy Data Security Unit; RAM Based Security when HDD is not installed
Scan-to-USB/SD, Scan-to-Email (POP, SMTP, TCP/IP); Scan-to-Folder (SMB/FTP/NCP); Network TWAIN Scanning; WSDScanner for Vista
Scanning Features
PDF Encryption, Preview Before Transmission (TX Preview), Drop Out Color Send, Simultaneous Fax and Scan, Scan-to-Email/SMB/FTP/URL, LDAP Support, TWAIN Scanning Other Printer Features
10 groups (max. 100 numbers per group with HDD option)
User Function Key
3 keys
Fax Features
Detection of Misplaced Documents, Double Check Destination Address, Direct SMTP, Simultaneous Fax and Scan, Fax Forward to Email/Folder, Internet Fax (T.37), IP Fax (T.38)*, LAN Fax, Paperless Fax*, LDAP Support
Footnotes
*HDD Option Required
Paper Feed
Paper Feed Unit PB1040 (Option) Paper Size 8.5" x 11" SEF, 8.5" x 14" SEF (A4/LT/LG) Paper Weight 16 – 24 lb. Bond (60 – 90 g/m2) Paper Capacity 500 sheets x 1 or 2 Trays
Notes
See Accessories Tab for a complete list of options
